FlowMap - Advanced Flowchart Generator Plugin for Dify

Author: sawyer-shi
Email: sawyer36@foxmail.com
Version: 0.0.4
Type: Dify Plugin
Repository: GitHub

Version Information

• Current Version: v0.0.4
• Release Date: 2026-06-21
• Compatibility: Dify Plugin Framework
• Python Version: 3.12+

Version History

• v0.0.4 (2026-06-21): Added AI Flowchart tool with Dify LLM model selection, plain text to Mermaid generation, top-bottom/left-right/free layout selection, and optional Mermaid source download.
• v0.0.3 (2026-03-15): Updated element overlap prevention algorithm to ensure elements do not cover each other.
• v0.0.2 (2025-10-18): Added free layout flowchart functionality, fixed bugs from previous versions, improved software stability and reliability.
• v0.0.1 (2025-09-12): Initial release with smart branch detection, colorful arrow labels, and advanced layout optimization

Description

A powerful flowchart generation plugin that converts Mermaid syntax or AI-summarized plain text to beautiful, intelligent flowcharts with advanced layout optimization and branch-aware positioning.

✨ Key Features

• 🎨 Intelligent Layout System

  • Smart branch detection and free layout for complex flowcharts
  • Grid layout for linear processes
  • Automatic canvas sizing to prevent element overflow

• 📐 Multiple Layout Directions

  • Left-to-right layout (LR)
  • Top-to-bottom layout (TB)
  • Branch-aware positioning

• 🌈 Colorful Arrow Labels

  • Intelligent color mapping based on label semantics
  • Support for Chinese and English labels
  • Customizable color themes

• 📝 Dual Format Support

  • Full Mermaid syntax support with labeled arrows
  • Markdown list conversion
  • Automatic text type detection

• 🤖 AI Flowchart Generation

  • Select any available Dify LLM model directly in the tool
  • Convert plain text into clean Mermaid flowchart syntax
  • Choose top-bottom, left-right, or free layout output
  • Optionally download the AI-generated Mermaid source

• 🎭 Rich Themes

  • Modern theme with gradient effects
  • Business professional theme
  • Classic minimalist theme
  • Custom theme support

• 🔧 Local Processing

  • Local Generation: Flowcharts generated locally, no API Key required, no external network or services needed
  • Secure & Reliable: Data stays private, completely offline processing, protects user privacy
  • No external API dependencies
  • Fast generation with matplotlib
  • Privacy-focused design
  • High-quality PNG output

🚀 Quick Start

1. Download from Dify Plugin Marketplace

   • Go to Dify Plugin Marketplace
   • Search and download flow_map plugin
   • Enable FlowMap plugin in your workspace

2. AI Flowchart ⭐

   • Configure an available LLM model in Dify
   • Select the ai_flow_map / AI Flowchart tool
   • Choose the LLM model, paste plain text, and select the output layout
   • Run the tool to generate a PNG flowchart locally

3. Manual LLM Integration

   • Add an LLM node in your Dify workflow
   • Use the simplest prompt: "Summarize user input #context# into Mermaid flowchart text format"
   • Connect LLM output to FlowMap plugin input

Basic Usage Examples

Top-to-bottom layout

Left-to-right layout

📚 API Reference

AI Flowchart Tool

Input Parameters:

• model_config (model-selector, required): LLM model selected in Dify
• text_content (string, required): Plain text to summarize into a flowchart
• layout_mode (string, optional): top_bottom, left_right, or free
• theme (string, optional): Theme name (modern/business/classic/tech/minimal)
• filename (string, optional): Base filename for the downloadable Mermaid source
• download_mermaid (boolean, optional): Output the AI-generated Mermaid file

Output:

• Success: PNG image + text summary + JSON details
• Optional: Mermaid source file when download_mermaid=true
• JSON includes layout_mode, theme, and generated_mermaid

Mermaid Left-Right Tool

Input Parameters:

• text (string, required): Mermaid syntax flowchart text
• theme (string, optional): Theme name (modern/business/classic)

Output:

• Success: PNG image + text summary
• Format: "Successfully generated left-right layout flowchart. File size: X.XXM. Contains X nodes and X connections."

Mermaid Top-Bottom Tool

Input Parameters:

• text (string, required): Mermaid syntax flowchart text
• theme (string, optional): Theme name (modern/business/classic)

Output:

• Success: PNG image + text summary
• Format: "Successfully generated top-bottom layout flowchart. File size: X.XXM. Contains X nodes and X connections."

🛠️ Advanced Features

Smart Branch Detection

The plugin automatically detects branching scenarios in your flowchart and switches layout algorithms:

• Linear Flow: Uses grid layout for optimal alignment
• Branching Flow: Uses free layout to prevent overlap
• Complex Flow: Automatically expands spacing and uses Bezier curve routing with orthogonal fallback to reduce line interference in dense free-layout diagrams

Colorful Arrow Labels

Supports labeled arrows with intelligent color mapping

Theme Customization

Available themes with different visual styles:

• Modern: Clean design with gradients
• Business: Professional corporate style
• Classic: Traditional minimalist look

🔧 Development

Project Structure

flow_map/
├── tools/                  # Core tools implementation
│   ├── ai_flow_map.py      # AI text-to-flowchart tool
│   ├── mermaid_lr.py      # Left-right layout tool
│   ├── mermaid_tb.py      # Top-bottom layout tool
│   ├── mermaid_free.py    # Free layout tool
│   └── optimized_layout.py # Advanced layout engine
├── provider/              # Provider configurations
├── test/                  # Comprehensive tests
├── manifest.yaml          # Plugin manifest
├── main.py               # Entry point
└── README.md             # Documentation

🔍 Technical Details

Branch-Aware Layout Algorithm

• Branch Detection: Automatically identifies decision nodes with multiple outgoing connections
• Free Layout: Hierarchical positioning based on connection levels
• Canvas Adaptation: Dynamic canvas sizing (up to 2.5x node count)
• Collision Avoidance: Smart spacing with 70% effective area usage
• Complex Routing: Dense free-layout flowcharts use Bezier curve fan-out, per-edge channel offsets, orthogonal fallback, canvas-bounded routing, and label collision avoidance

Performance Optimization

• Matplotlib Backend: High-quality vector graphics
• Memory Efficient: Local processing without external APIs
• Fast Rendering: Optimized for complex flowcharts

Developer Information

• Author: @sawyer-shi
• Email: sawyer36@foxmail.com
• License: Apache License 2.0
• Source Code: https://github.com/sawyer-shi/dify-plugins-flow_map
• Support: Through Dify platform, GitHub Issues, and email

License Notice

This project is licensed under the Apache License 2.0. See the LICENSE file for the full license text.

---
